10,000 Gallon Precision Stainless Vertical S/S Jacketed Prop Agitated Mixing Tank

Loeb # 72099 Model
OEM Precision Stainless
Year 1996 Serial 1703
Electrical Location ILLINOIS
Condition Asis Size 10,000.00
Lease for only 1,440.03 / mo. Rent for only N/A
Have one of these to sell? ITEM SOLD: Need One Of These?
10,000 Gallon Precision Stainless Vertical 316L S/S Jacketed Prop Agitated Mixing Tank. Approximate 144 in diameter x 142 in straight side. Dished top and bottom heads. Insulated, 304 stainless steel dimple jacket rated 90 psi at -20 to 200 degrees F. Internal rated Atmos at -20 to 200 degrees F. Stainless steel agitator bridge with top entering Lightnin 4 Blade Prop Agitator, model 780-QC-75, approximate 5 in diameter shaft with (2) 4-blade turbines. Driven by 100 HP, 3/60/460 volt, 1785 rpm gearmotor, 32.01 to 1 ratio. (4) Sidewall baffles, spray ball. Openings top: 24 in manway with cover, (1) 8 in, (1) 4 in, (3) 3 in, (1) 2 in, side: (3) 3 in, (1) 1-1/2 in. 4 in Center bottom outlet. Mounted on (4) stainless steel legs. Load Cells. National Board# 6246.
